Documentation -- Reference Pages -- accessor

Table Of Contents

Subsections

Operators

Operators

↑ aktive format as d2

Syntax: aktive format as d2 src [→ definition]

Converts the internal DAG representation of the image into a D2 graph format and returns the resulting string.

Despite the naming the operator is not strict. It does not access the input's pixels at all, only the meta information of the pipeline.

Input Description
src Source image

Examples

@1
(assets/butterfly.ppm)		 @2
(charcoal)		 aktive format as d2 @2

@1 (assets/butterfly.ppm)
geometry(0 0 380 250 3)		 @2 (charcoal)
geometry(0 0 380 250 1)		  # -*- d2 -*-
 direction: left
 1: "aktive read from netpbm\n(path tests/assets/butterfly.ppm)"
 1.shape: document
 1.style.fill: lightgreen
 2: "aktive op view\n(port {-1 -1 382 252})"
 2.shape: oval
 1 -> 2
 3: "aktive op tile max\n(radius 1)"
 3.shape: oval
 2 -> 3
 4: "aktive op view\n(port {-1 -1 382 252})"
 4.shape: oval
 1 -> 4
 5: "aktive op tile min\n(radius 1)"
 5.shape: oval
 4 -> 5
 6: "aktive op math sub"
 6.shape: oval
 3 -> 6
 5 -> 6
 7: "aktive op math1 invert"
 7.shape: oval
 6 -> 7
 8: "aktive op math1 gamma expand"
 8.shape: oval
 7 -> 8
 9: "aktive op color scRGB to Grey"
 9.shape: oval
 8 -> 9
 10: "aktive op math1 scale\n(factor 0.01)"
 10.shape: oval
 10.style.fill: orange
 9 -> 10

↑ aktive format as markdown

Syntax: aktive format as markdown src [→ definition]

Converts the internal DAG representation of the image into a Markdown table and returns the resulting string.

Despite the naming the operator is not strict. It does not access the input's pixels at all, only the meta information of the pipeline.

Input Description
src Source image

Examples

@1
(assets/butterfly.ppm)		 @2
(charcoal)		 aktive format as markdown @2

@1 (assets/butterfly.ppm)
geometry(0 0 380 250 3)		 @2 (charcoal)
geometry(0 0 380 250 1)		  ||Id|Command|Config|Inputs|Notes|
 |:---|:---|:---|:---|:---|:---|
 |FILE|1|aktive read from netpbm|path tests/assets/butterfly.ppm||FO(2): 2, 4|
 ||2|aktive op view|port {-1 -1 382 252}|1||
 ||3|aktive op tile max|radius 1|2||
 ||4|aktive op view|port {-1 -1 382 252}|1||
 ||5|aktive op tile min|radius 1|4||
 ||6|aktive op math sub||3, 5||
 ||7|aktive op math1 invert||6||
 ||8|aktive op math1 gamma expand||7||
 ||9|aktive op color scRGB to Grey||8||
 |OUT|10|aktive op math1 scale|factor 0.01|9||

↑ aktive format as tclscript

Syntax: aktive format as tclscript src [→ definition]

Converts the internal DAG representation of the image into a Tcl script and returns the resulting string.

Despite the naming the operator is not strict. It does not access the input's pixels at all, only the meta information of the pipeline.

Input Description
src Source image

Examples

@1
(assets/butterfly.ppm)		 @2
(charcoal)		 aktive format as tclscript @2

@1 (assets/butterfly.ppm)
geometry(0 0 380 250 3)		 @2 (charcoal)
geometry(0 0 380 250 1)		  set file1 [aktive read from netpbm path tests/assets/butterfly.ppm] ;# FO(2): tmp2, tmp4
 set tmp2 [aktive op view $file1 port {-1 -1 382 252}]
 set tmp3 [aktive op tile max $tmp2 radius 1]
 set tmp4 [aktive op view $file1 port {-1 -1 382 252}]
 set tmp5 [aktive op tile min $tmp4 radius 1]
 set tmp6 [aktive op math sub $tmp3 $tmp5]
 set tmp7 [aktive op math1 invert $tmp6]
 set tmp8 [aktive op math1 gamma expand $tmp7]
 set tmp9 [aktive op color scRGB to Grey $tmp8]
 set result [aktive op math1 scale $tmp9 factor 0.01]

↑ aktive op query colorspace

Syntax: aktive op query colorspace src [→ definition]

Returns the name of the color space the input is in.

If no colorspace is set then sRGB is assumed for 3-band images, and grey for single-band images.

For anything else an error is thrown instead of making assumptions.

Input Description
src Source image

Examples

@1
 		 aktive op query colorspace @1

@1
geometry(0 0 256 256 3)		  sRGB

↑ aktive query id

Syntax: aktive query id src [→ definition]

Returns the input's implementation-specific image identity.

Input Description
src Source image

↑ aktive query inputs

Syntax: aktive query inputs src [→ definition]

Returns a list of the input's inputs.

For an image without inputs the result is the empty list.

Input Description
src Source image

↑ aktive query params

Syntax: aktive query params src [→ definition]

Returns a dictionary containing the input's parameters.

For an image without parameters the result is the empty dictionary.

Input Description
src Source image

Examples

@1
(zone width 32 height 32)		 aktive query params @1

@1 (zone width 32 height 32)
geometry(0 0 32 32 1)		  width 32 height 32

@1
(gradient width 32 height 32 depth 1 first 0 last 1)		 aktive query params @1

@1 (gradient width 32 height 32 depth 1 first 0 last 1)
geometry(0 0 32 32 1)		  width 32 height 32 depth 1 first 0.0 last 1.0

↑ aktive query setup

Syntax: aktive query setup src [→ definition]

Returns a dictionary containing the input's setup.

This includes type, geometry, and parameters, if any. The inputs however are excluded.

Input Description
src Source image

Examples

@1
(zone width 32 height 32)		 aktive query setup @1

@1 (zone width 32 height 32)
geometry(0 0 32 32 1)		  type image::zone domain {x 0 y 0 width 32 height 32 depth 1} config {width 32 height 32}

@1
 		 aktive query setup @1

@1
geometry(0 0 32 32 1)		  type image::gradient domain {x 0 y 0 width 32 height 32 depth 1} config {width 32 height 32 depth 1 first 0.0 last 1.0}

↑ aktive query type

Syntax: aktive query type src [→ definition]

Returns the input's type.

Input Description
src Source image

Examples

@1
 		 aktive query type @1

@1
geometry(0 0 32 32 1)		  image::zone

@1
 		 aktive query type @1

@1
geometry(0 0 32 32 1)		  image::gradient
