Documentation -- Reference Pages -- transform effect

<anchor='top'> Table Of Contents

• transform ↗

Operators

• aktive effect blur
• aktive effect charcoal
• aktive effect emboss
• aktive effect jitter gauss
• aktive effect jitter uniform
• aktive effect max-rgb
• aktive effect min-rgb
• aktive effect sharpen
• aktive effect sketch
• aktive effect swirl
• aktive effect wobble

Operators

---

↑ aktive effect blur

Syntax: aktive effect blur src ?(param value)...? [→ definition]

Returns blurred input, per the specified blur radius.

Input	Description
src	Source image

Parameter	Type	Default	Description
radius	double	2	Blur kernel radius. Defaults to 2.

Examples

@1	aktive effect blur @1 radius 16
geometry(0 0 128 128 1)	geometry(16 0 96 128 1)

@1	aktive effect blur @1 radius 16
geometry(0 0 128 128 1)	geometry(16 0 96 128 1)

---

↑ aktive effect charcoal

Syntax: aktive effect charcoal src ?(param value)...? [→ definition]

Returns a grey image with a charcoal-like sketch of the sRGB input.

Input	Description
src	Source image

Parameter	Type	Default	Description
light	bool	no	Artistic choice between stronger and lighter sketch lines.

Examples

@1 (assets/butterfly.ppm)	aktive effect charcoal @1
geometry(0 0 380 250 3)	geometry(0 0 380 250 1)

@1 (assets/butterfly.ppm)	aktive effect charcoal @1 light yes
geometry(0 0 380 250 3)	geometry(0 0 380 250 1)

---

↑ aktive effect emboss

Syntax: aktive effect emboss src [→ definition]

Returns embossed input.

Input	Description
src	Source image

Examples

@1	aktive effect emboss @1
geometry(0 0 128 128 1)	geometry(1 1 126 126 1)

---

↑ aktive effect jitter gauss

Syntax: aktive effect jitter gauss src ?(param value)...? [→ definition]

Returns the input with a jitter effect based on gaussian noise applied to it. Visually this looks like frosted glass.

The underlying operation is aktive warp noise gauss.

Input	Description
src	Source image

Parameter	Type	Default	Description
interpolate	str	bilinear	Interpolation method to use
seed	uint	[expr {int(4294967296*rand())}]	Randomizer seed. Needed only to force fixed results.
mean	double	0	Mean of the desired gauss distribution.
sigma	double	1	Sigma of the desired gauss distribution.

Examples

@1	aktive effect jitter gauss @1 sigma 4 seed 703011174
geometry(0 0 128 128 1)	geometry(0 0 128 128 1)

@1 (assets/sines.ppm)	aktive effect jitter gauss @1 sigma 4 seed 703011174
geometry(0 0 256 256 3)	geometry(0 0 256 256 3)

@1 (assets/butterfly.ppm)	aktive effect jitter gauss @1 sigma 4 seed 703011174
geometry(0 0 380 250 3)	geometry(0 0 380 250 3)

---

↑ aktive effect jitter uniform

Syntax: aktive effect jitter uniform src ?(param value)...? [→ definition]

Returns the input with a jitter effect based on uniform noise applied to it. Visually this looks like frosted glass.

The underlying operation is aktive warp noise uniform.

Input	Description
src	Source image

Parameter	Type	Default	Description
interpolate	str	bilinear	Interpolation method to use
seed	uint	[expr {int(4294967296*rand())}]	Randomizer seed. Needed only to force fixed results.
min	double	0	Minimal noise value
max	double	1	Maximal noise value

Examples

@1	aktive effect jitter uniform @1 min 1 max 6 seed 703011174
geometry(0 0 128 128 1)	geometry(0 0 128 128 1)

@1 (assets/sines.ppm)	aktive effect jitter uniform @1 min 1 max 6 seed 703011174
geometry(0 0 256 256 3)	geometry(0 0 256 256 3)

@1 (assets/butterfly.ppm)	aktive effect jitter uniform @1 min 1 max 6 seed 703011174
geometry(0 0 380 250 3)	geometry(0 0 380 250 3)

---

↑ aktive effect max-rgb

Syntax: aktive effect max-rgb src [→ definition]

Returns an image suppressing at each pixel of the input the bands not reaching the max of the bands at that location.

For a single-band input this is a no-op.

Despite the use of rgb in the operator name this operator works on all multi-band images, regardless of the exact number or their semantic interpretation.

Idea from https://docs.gimp.org/2.8/en/plug-in-max-rgb.html

Input	Description
src	Source image

Examples

@1 (assets/butterfly.ppm)	aktive effect max-rgb @1
geometry(0 0 380 250 3)	geometry(0 0 380 250 3)

---

↑ aktive effect min-rgb

Syntax: aktive effect min-rgb src [→ definition]

Returns an image suppressing at each pixel of the input the bands not falling to the min of the bands at that location.

For a single-band input this is a no-op.

Despite the use of rgb in the operator name this operator works on all multi-band images, regardless of the exact number or their semantic interpretation.

Idea from https://docs.gimp.org/2.8/en/plug-in-max-rgb.html

Input	Description
src	Source image

Examples

@1 (assets/butterfly.ppm)	aktive effect min-rgb @1
geometry(0 0 380 250 3)	geometry(0 0 380 250 3)

---

↑ aktive effect sharpen

Syntax: aktive effect sharpen src [→ definition]

Returns sharpened input.

Input	Description
src	Source image

Examples

@1	aktive effect sharpen @1
geometry(0 0 128 128 1)	geometry(1 1 126 126 1)

---

↑ aktive effect sketch

Syntax: aktive effect sketch src [→ definition]

Returns image with a general sketch of the input.

Input	Description
src	Source image

Examples

@1	aktive effect sketch @1
geometry(0 0 128 128 1)	geometry(0 0 128 128 1)

@1	aktive effect sketch @1
geometry(0 0 128 128 1)	geometry(0 0 128 128 1)

---

↑ aktive effect swirl

Syntax: aktive effect swirl src ?(param value)...? [→ definition]

Returns the input with a swirling effect applied to it.

This effect applies around the specified center, with fixed rotation phi, a base rotation from, and a decay factor.

The rotation angle added to a pixel is given by phi + from * exp(-radius * decay), where radius is the distance of the pixel from the center. A large decay reduces the swirl at shorter radii. A decay of zero disables the decay.

All swirl parameters are optional.

The underlying operation is aktive warp swirl.

Input	Description
src	Source image

Parameter	Type	Default	Description
interpolate	str	bilinear	Interpolation method to use.
center	point	{}	Center of the swirl, default center of the image.
phi	double	0	In degrees, fixed rotation to apply. Default none.
from	double	45	In degrees, swirl rotation at distance 0 from center.
decay	double	0.1	Rotation decay with distance from center.

Examples

@1	aktive effect swirl @1 decay 0.05 from 135
geometry(0 0 128 128 1)	geometry(0 0 128 128 1)

@1 (assets/sines.ppm)	aktive effect swirl @1 decay 0.01 from 135
geometry(0 0 256 256 3)	geometry(0 0 256 256 3)

@1 (assets/butterfly.ppm)	aktive effect swirl @1 decay 0.01 from 135
geometry(0 0 380 250 3)	geometry(0 0 380 250 3)

---

↑ aktive effect wobble

Syntax: aktive effect wobble src ?(param value)...? [→ definition]

Returns the input with a swirling effect applied to it.

This effect applies around the specified center, with base amplitude, frequency, chirp, and attenuation powers.

The effect modulates the distance from the center based on the formula sin (radius^chirp * frequency) * amplitude / (1+radius)^attenuation, where radius is the original distance.

All parameters, including the center are optional.

The underlying operation is aktive warp wobble.

Input	Description
src	Source image

Parameter	Type	Default	Description
center	point	{}	Center of the wobble, relative to the image location. Defaults to the image center.
amplitude	double	500	Base amplitude of the displacement.
frequency	double	2	Base wave frequency.
chirp	double	0.5	Chirp (power) factor modulating the frequency.
attenuation	double	0.6	Power factor tweaking the base 1/x attenuation.
interpolate	str	bilinear	Interpolation method to use.

Examples

@1	aktive effect wobble @1 center {100 50}
geometry(0 0 380 250 3)	geometry(0 0 380 250 3)
